Vehicle technical parameters |
|
|
Product Name |
garbage compression truck |
|
Overall dimensions（mm） |
7800×2300×2650 |
|
Gross Vehicle Weight（kg） |
11200 - 12000 |
|
Box volume (L) |
12000 |
|
Box material quality |
T700high-strength steel plate |
|
Maximum speed (km/h) |
95/105 |
|
Chassis technical parameters |
|
|
Chassis brand |
ISUZU |
|
Fuel type |
diesel |
|
compression ratio |
2.5 : 1 - 3 : 1 |
|
engine |
ISUZU(205hp) |
|
wheelbase（mm） |
3815/4200 |
|
Loading cycle time |
≤25 S |
|
Displacement（L) |
5193 |
|
Tire specifications |
235/75R17.5 |
