| Vehicle Technical Configuration Sheet | |
| Vehicle Type | Monitoring ambulance |
| Overall dimensions(mm) | 5998×2068×2775/2910 |
| Total mass(kg) | 4100/4495 |
| Wheelbase(mm) | 3750 |
| Fuel type | diesel |
| Rated passenger capacity | 7-8 people |
| Oxygen supply system | 2×10L |
| Negative pressure system | - 30~-120Pa |
| Cabin structure | Aluminum alloy frame + FRP inner and outer skins |
| Medical pod dimensions(mm) | 3200× 1700×1800 |
