Vehicle technical parameters |
|
|
Product Name |
greening sprinkler truck |
|
Overall dimensions（mm） |
8200×2500×3200 |
| Total mass（kg） |
16200 |
|
Curb weight（kg） |
6005-6730 |
|
Box volume (L) |
9760-10500 |
|
Box material quality |
Q235 carbon steel |
|
maximum speed（km/h） |
89 |
|
Chassis technical parameters |
|
|
Chassis brand |
DFL |
|
Fuel type |
diesel |
|
spray width（m） |
≥16 |
|
engine |
Yunnei (170 hp) |
|
wheelbase（mm） |
3800 |
|
Water cannon range（m） |
≥30 |
|
displacement（L) |
3800-5700 |
|
Tire specifications |
9.00R20/10.00R20/10R22.5 |
